Temperature Controller

 Switch the modes between cool and heat; Control temperature by setting the temperature set value and the difference value; Temperature calibration; Refrigerating control output delay protection; Alarm when temperature exceeds temperature limit or when sensor error.

Specification and size

· Front panel size: 75(L)x34.5(W)(mm)

· Mounting size: 71(L)x29(W)(mm)

· Product size: 75(L)x34.5(W)x85(D)(mm)

sensor length: 2m(include the probe)

· Technical parameters

· Temperature measuring range: -50°C~ 99°C

· Resolution: 0.1°C

· Accuracy: +1C(-50°C ~70°C)

· sensor error delay: 1 minute

· Power supply:12V 24V 110-220VAC 50Hz/60Hz

· Power consumption: < 3W

· Sensor: NTC sensor (1PC)

· Relay contact capacity: Cool(10A/250VAC);Heat(10A/250VAC)

· Ambient temperature: 0°C~ 60°C

· Storage temperature: -30°C ~75°C .

· Relative humidity: 20~ 85% (No condensate)
