Model No.

Light source

Infra-red LED

Red LED

Infra-red LED

Power source

24 to 220VAC(±10%, 50/60Hz)
12 to 110VDC(±10%, Ripple 10% or less)

Power consumption

4W or less for both projector and receiver

5W or less

Detecting distance

30m or less

10m or less

0.1 to 4m or less^*1

70cm or less
(white paper with 10cm)

Response time

20msec or less

Operating mode

Dark-ON

Light-ON

Control output

1C relay, 250VAC 3A or less(Resistance load), 30VDC 3A or less(Resistance load)
Mechanical life : 50 million times, Electrical life : 0.1 million times

Sensitivity adjuster

Not provided(Fixed)

Provided

Connection

Cable type(0.3mm²×5 cores, 2m long)^*2

Protective structure

IP66(IEC standard)
